1U Rackmount Chassis Supports ATX M.B. max. 12"x10.5" Depth 542mm 1x5.25"&1x3.5"&2x3.5" or 2x5.25"&1x3.5
Main Features
| Model: | GHI-106 |
| Max. Board Size: | Mini-ITX (6.7" x 6.7") |
| System Board Type: | Atom, Core I, Core2Duo, Pentium |
Specifications
| Standard: | EIA RS-310C 19" Rackmount Standard |
| Construction: | Heavy Duty Cold Rolled Electroplated Steel |
| Color: | Black (Standard), Beige or Custom |
| Drive Bays: | (Option A): 1x Slim CD-ROM, 1x Slim FDD, 1x 2.5"HDD (Option B): 1x Slim CD-ROM, 1x 3.5" HDD |
| Power Supply: | 1U Single 200W ATX P/S(Rear Installation) Max. Depth 150mm |
| Cooling Units: | 2 x (40 x 20mm = 7CFM ea) Fans (Optional) |
| Expansion Slot: | |
| Connector Port (front): | 2x USB Ports |
| Indicators: | |
| Buttons: | Power ON/OFF Momentary (Square), System Reset |
| Crossbar: | |
| Thermal Card: | NA |
| Front Door(s): | |
| Air Filter: | None |
| Dimensions(W x H x D): | 483 x 43 x 220mm(19" x 1.7" x 8.7") |
| Weight: | 3.8 kgs / 8.4 lbs |
| Cu. ft.: | |
| Carton Size: | 57.3 x 18.5 x 35.5 (22.6" x 7.3" x 14") |
| Humidity: | 5% - 95% Non-condensing |
| Product Applications: | |
Optional accessories
| HDD Drive Accessories: | |
| Slide Rails: | |
| Chassis Height: | 1U |
